DRAM Protocol Analyzer

JLA520A DDR6/LPDDR6 Protocol Analyzer
The JKI DRAM protocol analyzer system is the industry’s highest-performance DDR6/LPDDR6 protocol analyzer with deep acquisition memory depth up to 1TB and the highest sampling rate up to 64GHz. Our high-speed and powerful memory trace solutions enable you to debug and validate DDR-based memory systems up to 8 Gb/s

Large Memory for Data Capturing
- Large memory depth up to 1 TB allows you to debug very complex problems by long capture times.
Ultra-fast Sampling Speed
- Ultra-fast sampling speed up to 64 GHz allows you to capture data rates up to 8 Gb/s for all channels without any extra options.
Probe Solution
- To minimize signal degradation in the probe system, the analog module is separated from the digital module and placed as close as possible to the device.
Interposer Solution
- We provide a variety of interposers and connecting solutions: LPDDR6 interposers

Maximum Sample Rate
- Max. 32 GHz (2/4/8/16/32/64 GHz options)
Number of Channels: total 32 CH
- Per-pin termination level
- Per-pin threshold level
- Per-pin timing delay
Analysis mode
- Timing mode / Eye mode
Acquisition Memory
- Max. 1 TB (standard GB)
- Full memory depth up to 64 GHz
- Hardware data compression
Hysteresis settings for all channels
Host Interface: PCIe Gen5 x8
